I. Product Overview

This series of pure water oxygen generators utilizes Solid Polymer Electrolyte (SPE) oxygen generation technology, using pure water as the electrolyte and generating high-purity oxygen through electrolysis with titanium metal electrodes. The oxygen is then separated from water, dried, and purified before output, featuring stable pressure (fluctuation <0.001 MPa), on-demand production, and zero alkaline solution addition. It is suitable for laboratory, medical, and industrial applications.



I. Instrument Features

1. Smart Control System

One-touch operation: Simply press the power switch to start gas production, supporting continuous or intermittent operation.

Precise Monitoring: A high-definition LED digital display accurately shows flow rate (±1ml accuracy) and pressure values, with data being clear and easy to read.

Pressure-adaptive: When the pressure reaches the preset value (e.g., 0.4 MPa), the system automatically adjusts the gas output volume to ensure the output pressure fluctuation ≤ 0.001 MPa.

2. Low-maintenance design

Simplified Maintenance: Simply replenish with pure water or distilled water as needed.

3. Safety Protection

Anti-backflow Technology: Equipped with an internal anti-backflow device, eliminating the risk of liquid backflow.

Multiple Protection: Over-pressure and low-liquid level automatic shutdown ensures equipment and operation safety.

4 Efficient and Compact Structure

High conversion efficiency: Electrolytic cell efficiency ≥95%, maximum gas output up to 2000ml/min, meets high load requirements.
