Plastic Pallet Heat Welding Machine, also known as Plastic Pallet Welder or Plastic Pallet Heat Melting Welding Equipment, powered by a hydraulic system. The welding of plastic pallets is typically done with PP or PE plastics, which have good welding properties. Welding requirements: After welding, ensure the PE panel surface is smooth with no welding marks.
Introduction to Plastic Pallet Heat Sealing Machine
The plastic pallet welding machine mainly welds plastic parts through temperature-controlled heating plates. During welding, the heating plate is placed between two plastic components. As the workpieces approach the heating plate, the plastic begins to melt. After a predetermined heating time, the plastic on the workpiece surface reaches a certain degree of melting. At this point, the workpieces will separate from both sides, the heating plate is removed, and then the two workpieces are joined together. Once a certain welding time and depth are achieved, the entire welding process is complete.

Plastic Pallet Heat Plate Welding Machine Application Range
Suitable for tray welding in sizes up to 1200mm x 1200mm, with a maximum size of 1800mm x 1500mm.
The main features of the plastic pallet hot plate welding machine are its simple structure, easy operation, and high production efficiency. After welding, it meets the requirements for water tightness, air tightness, and durability. Suitable for welding various sizes of plastic parts for pallets and thermoplastic materials. It is a widely used, cost-effective, and high-efficiency welding process.

Key Technical Parameters of Plastic Pallet Heat Welding Machine
Power Supply: 380VAC
Power: 75 kW
Air Source: 0.8MPa, 1m³ Air Compressor
Control System: PLC (Programmable Logic Controller) and Human-Machine Interface Operation Screen
Plastic Pallet Welding Machine Working Surface Travel Space:
Dimensions (L*W*H): 1800*1500*200 mm
1800mm x 1500mm x 200mm
Machine Dimensions: 2500*3500*2120mm
Weight: 4,500 kg
Plastic Pallet Hot Plate Welding Machine Design Concept
1. Designed according to customer requirements, this equipment features a maximum welding area of 1.8m x 1.5m. The upper cold mold and hot mold are secured to the equipment's movable plate with bolts, while the lower cold mold utilizes a roller structure. The side employs an air-powered positioning mechanism, allowing for automatic positioning and removal of workpieces. Electrical and pneumatic connections are made with quick connectors for convenience, speed, and time-saving. Mold change mode: manual mold change. The upper cold mold and hot mold are of an integrated modular design for easy assembly and disassembly; the lower cold mold's fixed clamp is adjustable.

3. Equipment Structure: The entire machine is of frame structure, with an outer casing equipped with a door frame for easy mold replacement and equipment maintenance.

4. Transmission: Equipped with linear guideways (Taiwan ABBA), the transmission ensures stable and high-precision operation of the equipment. Cylinders serve as power sources.

5. Electrical Control Section: The electrical control system of the equipment utilizes a PLC control method (Delta) and a Chinese display touch screen (Delta).
Plastic pallet welding machines, standard thermal plate design with non-standard configuration.
