In various chemical industries, many materials are stored in bagged forms such as granules, powders, and crystals, including fertilizers like ammonium phosphate, bio-fertilizers, and organic fertilizers used in agricultural production; sugar, brown sugar, additives, and traditional Chinese medicine in the food industry; and feed granules in animal husbandry. Due to their inherent properties and storage limitations, these materials can become damp and caked over time, affected by seasons, temperature, and humidity. The solution to this caking phenomenon is to manually crush them using wooden sticks or hammers. This process is labor-intensive, time-consuming, and inefficient, prone to damaging packaging and still results in uneven crushing, failing to effectively address the problem of caking in various materials.

Product Advantages:

Single-shaft plate type agglomerate material disintegrator, suitable for pseudo-agglomerated materials.

The equipment features innovative design for easy maintenance. Its simple and compact structure occupies minimal space, operates smoothly with low noise, significantly reduces labor and intensity, and ensures that the loose process does not tear bags or damage inner packaging.

Application Range:

Broadly applicable for loosening agglomerated powdery and crystalline materials (in bags), primarily used in the compound fertilizer industry, chemical raw materials, sugar, salt, food additives, feed factories, alkalis, traditional Chinese medicine factories, etc. It can loosen clumped fertilizers or granular materials without damaging the packaging, restoring the flowability and looseness of the contents inside the bag. Suitable for bagged materials weighing between 20-50KG.

Operating Principle:

Bagged clinker material enters from the inlet, where it is subjected to vibration and compression by two vibration rollers of the (220KG heavy) vibration frame during its journey along the conveyor belt. The frequency of vibration is 1000 times per minute, and the processed material is then discharged through the outlet, completing the vibration and compression process to loosen the material.

Product Features

This model of vibration disperser features a simple and compact structure, occupies minimal space, delivers excellent dispersion results, operates smoothly, and is clean and environmentally friendly. The vibration and compression effectively resolve the issue of material agglomeration, while reducing pollution, safeguarding the health of operators, easing labor intensity, and enhancing production efficiency.

Due to the varying shapes and hardness of the material lumps, this equipment is equipped with a forward and reverse button switch. The purpose of the switch is that when encountering an obstructed entry, you can press the reverse button to reverse out and then re-enter.

Single vibration type plate agglomeration material vibration disperser, with a simple and compact structure, small land area, used for the loosening of agglomerated powdery and crystalline materials in various industries such as compound fertilizer, chemical raw materials, sugar, salt, food additives, feed mills, alkalis, traditional Chinese medicine factories, etc. It can loosen agglomerated fertilizers or granular materials, restoring the fluidity and looseness of the materials inside the bags, achieving excellent performance.

Single-Group Double-Roll Type

Brand: Qingdao Luqi  Model: LQDZ

Specification: Single Set of Double Roll Vibrator    Available for Customization as Required

Equipment Name: Single Vibration Double Roller Type Board Agglomeration Material Loosener

Usage: Designed for loosening various bagged materials, 20KG-50KG in weight, without packaging, without damaging the outer packaging, and without altering the original condition of the material.

Applicable Environment: Chemical Plants, Sugar Mills, Additive Factories

Work Environment: Hardened level floor in the workshop
