I. The Impact of Mechanical Vibration

When quartz crystal oscillators are subjected to any given shock or periodic mechanical vibration, such as piezoelectric speakers, piezoelectric buzzers, and horns, the output frequency and amplitude will be affected. This phenomenon can impact the communication quality of communication equipment. Although the crystal design can minimize the impact of mechanical vibrations, we recommend pre-inspection and operation according to the following installation guidelines.

Section II: Impacts During Automatic Installation

Automated installation and vacuuming can cause shocks that may damage product characteristics and affect these products. Set installation conditions to minimize shocks as much as possible and ensure that the product characteristics are not affected prior to installation. Recheck installation conditions when conditions change. Additionally, ensure that crystal products are not struck by the machine or other circuit boards during installation and post-installation.

III. Operations

Do not use tweezers or any hard tools to directly contact the surface of the IC.

Active Oscillators, Temperature Compensated Crystal Oscillators, DSK321STD Crystal Oscillator Usage Environment (Temperature and Humidity).

Please use SMD crystal oscillator products within the specified temperature range, which includes both the ambient and seasonal temperature variations. In high humidity environments, failures may occur due to condensation. Avoid the formation of condensation.
