JT Series Diesel Cleaning and Lubricating Machine Equipment Name: JTC-400Ⅱ Type Through-Type Diesel Cleaning and Lubricating Machine
JT Series Diesel Cleaning and Lubricating Equipment Process Flow: Loading → Kerosene Cleaning → Compressed Air Blowing Oil (Air Source Self-contained) → Atomized Lubricating → Unloading
Main Technical Parameters of JT Series Diesel Cleaning Oiling Machine
Dimensions: L5100 x W1500 x H2200
2. Cleaning Medium: Diesel
3. Fuel Tank Capacity: 300L x 2
4. Material Loading Height: 750mm
5. By size: 400×400
6. Cleaning Pump: N=5.5 Kw
7. Power of transmission motor: 0.75 Kw
8 Lubricating Pump: N=0.55KW, Lubricating Pressure: 0-0.25Mpa
9. Feed Speed: Continuously adjustable from 0.18 to 1.8 m/min
11. Oil mist filter fan: N=1.1 kW (2 sets)
12. Fuel Tank Electric Heating Tube Power: 1KW × 3 = 3KW
13. Peak Power: ≤12Kw
14. Total Quantity: 2000KG
