American Orolong 310C-06A Desktop Conductivity MeterProduct Description: The 310C-06A Desktop Pure Water Conductivity Meter caters to the measurement needs of various users. With a large-screen LCD display, you can quickly obtain measurement information. It can display conductivity/TDS/salinity/resistivity and temperature, as well as icons for time, date, sample number, user number, and calibration points, which are very helpful for measurements. Advanced features such as stability and mean value ensure accurate measurement results in any situation. Product Features: The operating interface offers a choice of 6 languages including Chinese and English. The AUTO-READTM feature locks the reading and displays an indicator icon when the data is stable. The timer reading function automatically records readings at set intervals. It has an internal seawater salinity curve. You can choose between linear or ISO/EN 27888 curves for TDS measurement. Up to 2000 sets of measurement data can be saved, in compliance with GLP standards. Data can be transmitted or the instrument software updated using USB or RS232 interfaces with the included data analysis software. Both desktop and portable instruments can use AA batteries or power adapters. The desktop model has an IP54 protection rating, while the portable model has an IP67 protection rating. Technical Specifications:
|
|
|
Star A Desktop Conductivity Meter
|
Star A Portable Conductivity Meter
|
|
Conductivity
|
Measurement Range
|
0.001μS – 3000mS
| |
|
Resolution
|
As low as 0.001μS or four significant digits
| ||
|
Relative Precision
|
0.5% reading
| ||
|
Reference Temperature
|
5、10、15、20、25℃
|
15、20、25℃
| |
|
Temperature Compensation Type
|
Linear (0 – 10.0%/°C), Non-linear, Ultra-pure water Non-linear, USP Water Limit Value
|
Linear (0 – 10.0%/°C), Nonlinear
| |
|
Electrode Constant Range
|
0.001 – 199.9
| ||
|
Calibration Point
|
[much] an additional 5 points
| ||
|
Calibration Editing Feature
|
Available
|
N/A
| |
|
Resistivity
|
Measurement Range
|
2Ω – 100MΩ
| |
|
Resolution
|
2Ω-cm
| ||
|
Relative Accuracy
|
0.5% of the reading
| ||
|
Salinity
|
Type
|
Actual Salinity or Seawater Salinity
|
Actual Salinity
|
|
Scope
|
0.01 - 80.0 ppt NaCl (relative) 0.01 – 42 ppt Actual Salinity
| ||
|
Resolution
|
0.01
| ||
|
Relative Accuracy
|
±0.1
| ||
|
TDS
|
Scope
|
0 – 200ppt
| |
|
Resolution
|
4 significant digits
| ||
|
Relative Accuracy
|
0.5% of the reading
| ||
|
TDS Factor Range
|
Linear 0.01 – 10.00
| ||
|
Temperature
|
Scope
|
-5 - 105℃
| |
|
Resolution
|
0.1
| ||
|
Relative Accuracy
|
±0.1
| ||
|
Temperature Calibration Function
|
Yes, 1 point.
| ||
|
Data Storage
|
Quantity
|
2,000 units, compliant with GLP standards
|
1,000 units, compliant with GLP standards
|
