Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant condensers. Glan Chemical Co., Ltd. guarantees cooperation.
Jining Green Chemical Technology Co., Ltd. (Abbreviated as Jining Green Cleaning Co.) was established in 2010 and specializes in industrial heat exchange equipment cleaning. The company boasts comprehensive business philosophy and the capability to research and develop industrial cleaning technologies. We undertake cleaning services for industrial equipment, corporate chemical equipment, power plant equipment, condensers, boilers, and boiler air preheaters; as well as air conditioning cleaning, heat exchange equipment cleaning, and cleaning of machinery and chemical equipment. Additionally, we provide cleaning services for refrigeration and heating equipment to remove scale.
Jining Greentech Cleaning Co. has dozens of cleaning machines with various models ranging from 10MPa to 250MPa, as well as more than a dozen chemical cleaning pump stations. Our main services include power plants, chemical factories, oil mills, food factories, corporate entities, heating equipment, and more. The company also provides long-term industrial heat exchanger cleaning and solution design services to industry clients.
Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry to standardize and regulate the cleaning of heat exchange equipment.
Chemical Cleaning Scale Removal Process
Recirculating closed-loop cleaning
Recirculating cleaning utilizes two existing parallel ash piping lines to form a loop, creating a recirculation system with the cleaning pump station. A certain concentration of acidic solution is added, which circulates through the ash water pipes for cleaning. As the acid washing decreases to a certain level, the acidic solution is continuously replenished. For short-distance single ash water pipes, if conditions permit, a temporary pipeline can be laid to form a recirculation loop for cleaning. This process must be carried out while the system is shut down, and it is complex and costly.
Pilot Cleaning
No two gray pipes should form a loop during cleaning; only single-pipe open circuit cleaning is allowed. The method involves connecting one end of the gray pipe to the cleaning unit, continuously preparing a specific concentration of cleaning solution in the mixing tank, and then injecting it into the gray pipe continuously or intermittently. This process requires additional cleaning equipment during shutdown, resulting in higher costs.
Continuous cleaning without shutdown
This process involves continuously injecting a certain amount of acidic solution while the ash pipeline is operating normally and not shut down, simultaneously adding a certain amount of ash-pipeline running cleaning inhibitor and pipeline cleaning descaler for open-loop cleaning. The primary function of the cleaning aids is to promote the reaction between the acidic solution and ash deposits at a specific concentration and flow rate, while also enhancing its solubility in water and reducing the formation of air blockages, ensuring the quality of ash pipeline cleaning.
The procedure is as follows: First, estimate the required acid amount based on the total scale in the pipeline before cleaning. Then, calculate the acid addition rate and the flow rate of the sludge pipeline running corrosion inhibitors and pipeline descaler based on the flow rate of the sludge water and acidity. During cleaning, collect samples at the sampling point at the front end of the sludge pipeline every 30 minutes to test acidity, and strictly control the acidity by adjusting the flow rate of acid addition. In the later stage of cleaning, collect samples at the end of the sludge pipeline every 15 minutes to test pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning can be deemed to be completed.
2. High-pressure water jet cleaning equipment
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, environmental friendliness, ease of operation, and safety.
Advantages of high-pressure water technology include:
(1) Excellent Cleaning Quality: High-pressure water jet cleaning of pipes and heat exchanger bores can completely remove scale and blockages inside, revealing the metal substrate. The high-pressure water jet, with its immense energy and supersonic speed, can fully destroy hard scale and blockages without causing any damage to the metal.
Due to the pressure of high-pressure water being less than the compressive strength grade of metal, high-pressure cleaning will not damage the substrate being cleaned.
(2) Rapid Cleaning Speed: Due to the combined crushing effects of water jet flushing, splitting, shearing, and abrasion, scale can be quickly broken and removed, several to ten times faster than traditional chemical methods, sandblasting, ball-shotting techniques, simple mechanical, and manual cleaning methods.
Components cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface chemicals must be rinsed off with clear water.
(3) No Environmental Pollution: Since high-pressure water jet cleaning uses pure water as the medium, it does not generate a large amount of dust like sandblasting, grit-blasting, or simple mechanical cleaning, which can pollute the atmosphere and harm health. It also does not produce a large volume of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning with pure water as the medium is odorless, tasteless, and non-toxic. After atomization, it can also reduce the dust concentration in the work area, lowering atmospheric dust from 80mg/m³ with other methods to below the national safety standards, thus causing no pollution.
Pipe Scale
(1) Classified by chemical composition, they include carbonate scale, sulfate scale, silicate scale, and mixed scale, etc. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively; mixed scale is usually a mixture of the above three types.
(2) Classified by physical properties, there are two types: hard scale that firmly adheres to the pot shell and pipe walls, and soft sediment that is loose and easily detached.
Lime scale primarily forms due to the salts like calcium and magnesium in the boiler feed water precipitating and adhering to the metal surface upon heating. Lime scale has a very low thermal conductivity, about 2 to 5 times that of ordinary steel. When lime scale accumulates on the boiler's heating surface, it significantly impairs heat transfer efficiency and affects the boiler's performance; it can also easily cause metal materials to burn out due to localized overheating, even leading to pipe explosion accidents; it accelerates galvanic corrosion, causing pipeline scale corrosion, and speeding up the damage to the heating surface. Lime scale should be promptly removed using mechanical or chemical methods after its formation.
Heat Exchanger & Refrigeration Equipment Cleaning - Choose GreenChem for Confidence
