Clean various heat exchangers, condensers, industrial pipelines, boilers, and steam power plant condensers. Glan Chemical Co., Ltd. offers guaranteed cooperation.

Jining Green Chemical Technology Co., Ltd. (简称 Jining Green Cleaning Co.) was established in 2010 and specializes in cleaning various industrial heat exchange equipment. The company boasts comprehensive business philosophy and the capability to research and develop industrial cleaning technologies. We undertake cleaning services for industrial, private enterprises, chemical equipment, power plant equipment, condensers, boilers, and economizers, as well as air conditioning units, heat exchangers, and mechanical and chemical equipment. We also handle cleaning of refrigeration and heating equipment for scale removal.
Fertilizer plant heat exchanger cleaning, reactor packing, tower - Shandong Yantai Laizhou

Jining Green Clean Company stocks dozens of cleaning machines with models ranging from 10mpa to 250mpa, as well as over a dozen chemical cleaning pump stations. Our primary services are to power plants, chemical factories, oil refineries, food processing plants, corporate entities, and heating equipment. The company also provides long-term industrial heat exchanger cleaning and design solutions for industry clients.

Our company has newly acquired domestic cleaning machines and imported cleaning equipment. We have hired experienced technical specialists in the cleaning industry, which has standardized and normalized the cleaning of heat exchange equipment.

Chemical Cleaning Scale Removal Process

Recirculating Closed Loop Cleaning

Recirculating cleaning utilizes two existing parallel ash piping lines to form a loop, creating a circulation system with the cleaning pump station. A certain concentration of acidic solution is added, which circulates through the ash water pipes for cleaning. As the acid washing decreases to a certain level, the acidic solution is continuously replenished. For short-distance single ash water pipelines, if conditions permit, a temporary pipeline can be laid to form a recirculation loop for cleaning. This process must be carried out while the system is shut down, and it is complex and costly.

Open road cleaning

No two gray pipes can form a loop during cleaning; only a single gray pipe can be used for open-circuit cleaning. The method involves connecting one end of the gray pipe to the cleaning unit, continuously preparing a certain concentration of cleaning solution in the mixture tank, and injecting it into the gray pipe continuously or intermittently. This process requires additional cleaning equipment during shutdown, resulting in higher costs.

Fertilizer factory heat exchanger cleaning, reactor packing column, Shandong Yantai Laizhou

Continuous operation cleaning

This process involves continuously injecting a certain amount of acidic solution while operating the ash conveying pipes, simultaneously adding a specific quantity of ash conveying pipe cleaning inhibitor and pipeline descaling agent for open-circuit cleaning. The primary function of the cleaning aids is to promote the reaction between the acidic solution and ash deposits at a certain concentration and flow rate, while also increasing its solubility in water and reducing the formation of air blockages, ensuring the quality of ash pipe cleaning.

The procedure is as follows: Before cleaning, first estimate the required acid quantity based on the total scale in the pipeline. Then, calculate the acid addition rate and the flow rate of the ash removal agent and pipeline descaler according to the flow rate and acidity of the gray water. During the cleaning process, take a sample every 30 minutes at the sampling point at the front of the ash pipe to test the acidity, and strictly control the acidity by adjusting the flow rate of acid addition. In the later stage of cleaning, take a sample every 15 minutes at the end of the ash pipe to test the pH value. When the pH value reaches a certain level and remains unchanged for 30 minutes, the cleaning process can be considered complete.
Fertilizer plant heat exchanger cleaning, reactor packing, and tower in Laizhou, Yantai, Shandong

2. High-pressure water jet cleaning equipment
High-pressure water jet cleaning offers advantages such as high efficiency, low cost, non-damaging to workpieces, environmental-friendly, easy operation, and safety.
Advantages of high-pressure water technology include:

(1) Excellent Cleaning Quality: The high-pressure water jet cleaning of pipeline and heat exchanger bores can completely remove scale and blockages inside, revealing the metal substrate. With immense energy and moving at supersonic speeds, the high-pressure water jet is fully capable of destroying hard scale and blockages without causing any damage to the metal.

High-pressure water cleaning will not damage the base material being cleaned, as the pressure is less than the compressive strength grade of the metal.

Fertilizer plant heat exchanger cleaning, reaction kettle, packing tower - Shandong Yantai Laizhou

(2) Fast Cleaning Speed: Due to the combined effects of water jet washing, wedge splitting, shearing, and grinding, scale can be quickly broken and removed, making the cleaning speed several to ten times faster than traditional chemical methods, sandblasting and shot peening techniques, simple mechanical, and manual methods.

Components cleaned with high-pressure water jetting do not require secondary cleaning; however, after chemical cleaning, the surface chemical agents must be rinsed off with clean water.

Fertilizer plant heat exchanger cleaning, reactor packing, tower - Shandong Yantai Laizhou

(3) No Environmental Pollution: Since high-pressure water jet cleaning uses pure water as the medium, it does not produce a large amount of dust like sandblasting, shot blasting, or simple mechanical cleaning, which can pollute the air and harm health. Nor does it generate a significant amount of waste liquid like some chemical cleaning methods, which can contaminate rivers, soil, and water quality. The water jet cleaning using pure water is odorless, tasteless, and non-toxic. After atomizing the jet, it can also reduce the dust concentration in the working area, lowering atmospheric dust levels from 80mg/m³ with other methods to below the national safety standards. Therefore, it does not cause any pollution.

Pipe Scale

(1) Categorized by chemical composition, they include carbonate scale, sulfate scale, silicate scale, and mixed scale. The main components of carbonate scale are calcium carbonate and magnesium carbonate; the main components of sulfate scale and silicate scale are calcium sulfate and silicate compounds, respectively; mixed scale is usually a mixture of the above three types.

Fertilizer plant heat exchanger cleaning, reactor packing, tower - Shandong Yantai Laizhou

(2) Categorized by physical properties, there are two types: hard scale that firmly adheres to the pot shell and tube walls, and loose sediment that is easy to detach.
Lime scale primarily forms due to the salts of calcium and magnesium in the boiler feed water that precipitate and adhere to the metal surface upon heating. Lime scale has a very low thermal conductivity, about 2 to 5 times less than ordinary steel, and when it accumulates on the boiler's heat transfer surface, it significantly worsens heat transfer efficiency, affecting the boiler's performance; it can easily cause metal materials to burn due to local overheating, potentially leading to pipe explosion accidents; it also accelerates galvanic corrosion, causing pipeline lime scale corrosion and speeding up the damage to the heat transfer surface. Once lime scale forms, it should be promptly removed using mechanical or chemical methods.

Heat exchanger and refrigeration equipment cleaning, choose Grean Chemicals with confidence.
