Nitrogen Vacuum Storage Box, Custom Vacuum Damp-Proof Cabinet, Components of Full-Automatic Vacuum Nitrogen Cabinet

Storage compartments (1-16), hinged storage doors (with seals and handles), control area (human-machine interface + switches + flow meters + emergency stop buttons, etc., to check the pressure and storage quantities of each compartment in real-time, even during power outages, ensuring the sealed compartment's gas pressure and content remain unchanged; effectively protects products and equipment; safe, reliable, convenient, and quick management, with simple maintenance), vacuum components (equipped with vacuum pumps + vacuum gauges + vacuum valves + vacuum piping through pressure conversion valves, connected to the main vacuum pipeline, with each compartment connected via branch pipes), nitrogen control components (nitrogen valves + connected through piping to each storage compartment).

Nitrogen Vacuum Storage Tank, Custom Vacuum Desiccator, Full Automatic Vacuum Nitrogen Cabinet Performance

Cavity Capacity: 300×300×300mm + Customized

Chamber: 1-16 separate boxes available, individual unit control

Material: Inner box made of SUS304 stainless steel, outer box made of high-quality cold-rolled steel electrostatic spraying or stainless steel

Minimum Vacuum Degree: ≤10 Pa, Digital Display

Human-Machine Interface: 7-inch color touch screen interface, with automatic/manual control options

Control System: Human-Machine Interface + PLC Control

Vacuum Pump: Vortex Dry Pump or Imported

Nitrogen Vacuum Storage Box, Customized Vacuum Moisture-Proof Cabinet, Expandable Full-Automatic Vacuum Nitrogen Cabinet

Temperature: RT - 200°F

Humidity: Humidity Monitoring

Oxygen Concentration: Real-time Oxygen Content Monitoring

Industrial Systems: MES systems and more
