Encapsulation-Specific Nitrogen Drying Oven, Photoresist Curing Dust-Free Drying Oven, Nitrogen Drying Oven Usage Steps
Sheet Mounting Curing: After the frame of the mounted sheet is completed, it is sent into the upstream oven. Close the chamber door, introduce nitrogen, and raise the clean oven temperature to 175°C. The curing process lasts approximately 1 hour, allowing the conductive silver adhesive used during the mounting process to solidify.
The heating temperature during the curing process of the coated film is 175°C. During this process, the silver conductive resin part is heated and decomposes to produce a small amount of organic waste gas (the amount of organic waste gas is calculated as 1.5% of the epoxy resin content), and the entire silver conductive adhesive volatilizes to produce organic waste gas. The main pollutants in this process are organic waste gas.
Encapsulation-Specific Nitrogen Drying Oven, Photoresist Curing Dust-Free Drying Oven, Nitrogen Drying Oven Performance
The inner lining is made of SUS304 stainless steel.
2. Intelligent controller, excellent temperature control performance；
3. Digital single-screen display of parameters such as temperature and time.
4. Made with stainless steel sheet perforation.
5. The LCD large-screen liquid crystal display shows all set and actual parameters.
6. The hot air circulation system consists of a fan that can continuously operate at high temperatures and appropriate air ducts, enhancing the uniformity of the temperature inside the workspace.
7. The interior cargo shelf is adjustable.
8. Equipped with a microcomputer P.I.D. temperature controller featuring over-temperature deviation protection and digital display, with timing function, ensuring stable and reliable temperature control.
9. Over-temperature alarm, timed shutdown, and temperature adjustment features.
Display Method | LCD Digital Display |
Power Voltage | AC220V 50HZ |
Temperature Control Range | Room Temperature+10～250℃ |
Temperature Resolution | 0.1℃ |
Volatility | ±0.5℃ |
Uniformity of temperature | ≤±1.5%℃ |
Input Power | 2500W |
InnerCavityDimensions (W*D*H) mm | 450*550*550 |
Dimensions (W*D*H) mm | 640*710*900 |
Loading Rack (Standard Equipment) | 2Block |
Timerange | 1～9999 min |
Nitrogen Control | Rotary flow meter control, adjustable flow |
Encapsulation-Specific Nitrogen Drying Oven, Photoresist Curing Dust-Free Oven, Nitrogen Drying Oven Manufacturer
