Kexin Custom Large Clocks, Belfry Clocks, Square Decorative Clocks, LED High-Brightness Night-Light Lighting

Yantai Kexin Clock Co., Ltd. produces tower clocks with precise timekeeping and zero error, mainly relying on the following technical guarantees:

1. GPS real-time time synchronization, achieving synchronization with satellite standard time, with the master control system's master clock having no cumulative error.

2. Reliable IoT technology and feedback supervision system for the subordinate clocks (large dials), ensuring synchronized operation with the master clock. The subordinate and master clocks automatically synchronize every 15 seconds. In case of a subordinate clock failure, an automatic alert is triggered with a suggested solution.

3. Our self-produced movement is the core component of the tower clock, crafted from babbitt bronze for the bearings and 45-grade steel that has undergone rigorous mechanical heat treatment, significantly enhancing the movement's wear resistance. The fully enclosed design ensures minimal maintenance and care, guaranteeing a lifespan of 50 years.

4. Professional installation personnel are the guarantee for the normal operation of the equipment. Our company has installation technicians and several well-trained高空workers. Our experience is that three parts depend on the equipment and seven parts on the installation. Local offices and service centers truly ensure that customers can buy with confidence and use without worries.

5. With years of technical accumulation, our company is capable of repairing various brands of tower clocks. To assure our customers of their choice, we promise a 3-year free warranty on all repairs.

Tower Clock Grand Clock Production and Installation Process

Estimated Project Duration: 30 calendar days

Including: Manufacturing Lead Time: 20 days

Transportation and installation timeline: 10 days

I. Production, guaranteed manufacturing timeline plan

1. Based on the signed contract. The day after the contract is signed, the company issues production schedules to all production departments (including various production workshops, the technical department, and the logistics center). The schedules detail: the dimensions, colors, functions, and shipment times of each clock. A detailed "Material Requirement Sheet" is also attached.

2. The technical department is responsible for determining the technical solution based on the specific requirements of the client's tender documents, and providing it to the production workshop for production. The logistics center, based on the "Material Requirement Sheet" and current inventory, drafts a detailed "Procurement Plan." The procurement plan is issued to: electronic component procurement specialist, outsourced procurement specialist, and bulk material procurement specialist. The required approximate funds are also notified to the finance department.

3. Begin procuring various materials from the second day onwards, with priority given to urgently needed supplies for production.

4. The company's existing stock of materials and spare parts, such as control systems and cores, will be immediately incorporated into production as per the contract requirements. By the 3rd to 13th day, the basic manufacturing of control systems and cores will be completed. Subsequently, they will gradually proceed to the debugging and trial operation processes.

5. Basic completion of the clock face manufacturing (外观件不需调试) within the 3rd to 13th day.

6. All packaging materials will be in place from the 8th to the 11th day, and the wooden boxes for packaging will be completed.

7. All debugging must be completed by the 18th day, followed by inspection prior to packaging, and completion of various packaging-related documents and forms.

8. All packaging is completed by the 19th day.

9. Notify Party A that the shipment is ready for dispatch, and confirm with Party A the specific unloading location and installation time.

10. The installer will arrive at the installation site ahead of schedule, as agreed by both parties, to prepare for the installation. The following day, they will inspect the goods together with Party A and commence the installation process.

Section II: Clock Equipment Transportation and Installation Plan:

(Part One) Packaging, Shipment, and Transportation Solutions

1. In terms of packaging, for general control instruments and computer accessories, we use cardboard boxes, filled with shock-absorbing foam and moisture-proof plastic bags. For clock faces, valuable items (such as control boxes, clock hands, and dials), and goods weighing over 20 kg, we add an outer wooden crate (made of high-quality plywood) to the cardboard box. Similarly, shock-absorbing foam is also installed between the wooden and cardboard boxes. All packaging is neat, attractive, and reliable, loaded onto trucks according to road transportation requirements to ensure goods arrive at the destination intact.

2. Each carton contains a detailed product packing list, factory certificate of conformity, quality inspection certificate, manual, etc. The carton is sealed after being inspected and approved by the inspector.

Each package box is imprinted with the shipper, departure station, consignee, destination, product name, gross/net weight, total number of pieces in this batch, contract number, etc. Additionally, it features the "Three-Proof" label.

4. Transportation: For this batch of *** equipment, we will select the most suitable transportation method, such as road or rail, based on the installation location of the tower clock project and the requirements for equipment transportation. We guarantee the safe, accurate, and timely delivery of the goods to the destination. Any losses due to loss or damage will be borne by us. Within 48 hours prior to the shipment of the equipment, we will send the recipient a fax with details including the station name, quantity, estimated installation date, contract number, material name, quantity, gross weight, volume, amount, and name of the transportation vehicle, as well as the equipment shipment schedule.

5. Arrival Inspection and Handover

Upon arrival at the destination, our project manager and the buyer's representative will jointly inspect the goods in accordance with the contract. The inspection scope includes the quantity, specifications, model, quality, and performance parameters of the equipment. Both parties will sign and stamp the delivery (receiving) document, which serves as a crucial basis for operational handover. In case any goods do not meet the buyer's requirements, the buyer has the right to refuse acceptance or request a replacement, and the resulting costs will be borne by our company.

现场安装检查及进场

1. On-site Installation Inspection

1) Upon arrival of the goods on site, the installation personnel will inspect the number of packaging boxes and check for any damage or missing items, in accordance with the "Shipment Registration Form," together with the recipient.

2) Inspect the goods inside the packaging boxes with the buyer, and count each item according to the packing list.

3) Briefly describe the name, quantity, use, and storage requirements of various goods to facilitate the provider in securing a safe storage location.

2. Installation On-Site

1) All goods shall be delivered in accordance with the installation schedule as per the contract or mutually agreed upon by both parties. Prior to installation, a storage location for the goods shall be agreed upon with Party A to ensure a safe storage area for the uninstalled goods.

2) Collaborate with the buyer to determine installation conditions and make necessary modifications to those that do not meet requirements, ensuring a safe and smooth installation.

3) Inform the buyer of the approximate time for acceptance to allow them to prepare accordingly.

(3) Clock Equipment Installation

Equipment Installation Steps:

1. Assemble the clock face on the designated work surface.

2. Rent suitable hoisting equipment and employ the whole-set hoisting method to weld or bolt the steel frame of the large bell to the reserved iron parts of the bell tower.

3. Reserve piping for the subclock and master clock, lighting lines, and speakers to amplifiers.

4. Accept scale lighting wire, movement lighting wire.

5. Install the speaker and connect the speaker power cord.

6. Connect the motor wire and feedback wire to the motor and feedback switch on the core.

7. Connect all motor wires, feedback lines, lighting wires, and speaker wires to the master clock system and the control room where the amplifier is located.

8. Connect to the GPS time synchronization system.

9. Connect and debug the monitoring microcomputer.

III. Clock Equipment Operation and Debugging

Commissioning period: 3 calendar days, with simultaneous training for the client's designated operators during the debugging process.
