Japan Magnescale Caliper Sensor DK805SAR
Measurement Range: 5mm, 12mm, 30mm
Resolution: 0.1µm, 0.5µm
Accuracy: 1µm p-p ~ 1.7µm p-p (varies by model)
Response Speed: 80m/min at 0.1µm resolution, 250m/min at 0.5µm resolution
Bearings Structure: Utilizing high durability ball spline bearings, enhancing sliding performance
Swipes: Over 320 million or more (testing continues as of January 2021)
Protection Level: Supports IP67 (when straight or right-angled and气管 is installed)
Built-in origin
Output Signal: A/B Phase (Pulse), Home Position (Differential Line Driver Signal with Output Voltage Difference)
Available with flanges for secure fastening.
| Main Specifications | ||
|---|---|---|
※1 The items marked with () are type B ※2 Excludes the internal box and connector parts ※3 Right-angled and φ4mm tube used ※4 Excludes cable parts and inserts ※5 The shapes and sizes of certain parts differ from the previous DK800 series models. Changes to the content will be made without prior notice. | ||
| Model | High-resolution model | Universal Resolution Type |
| DK805SAR，DK805SALR，DK805SAFR，DK805SAFLR DK805SBR，DK805SBLR，DK805SBFR，DK805SBFLR | DK805SAR5，DK805SALR5，DK805SAFR5，DK805SAFLR5 DK805SBR5，DK805SBLR5，DK805SBFR5，DK805SBFLR5 | |
| Measurement Range | 5mm | |
| Resolution | 0.1µm | 0.5µm |
| Accuracy (at 20℃) | 1µm p-p | 1.5µm p-p |
| Measuring Force (at 20℃) | Up: 0.35 ± 0.25 N | |
| Horizontal: 0.40 ± 0.25 N | ||
| Down: 0.45 ± 0.25 N | ||
| Operating Temperature Range | 0 to +50℃ (No condensation) | |
| Storage temperature range | -20 to +60℃ (90%RH or less) | |
| Response Speed ※1 | 80m/min (42m/min) | 250m/min (100m/min) |
| Spindle Drive Method | Spring Compression (All Models) Air-driven through vacuum aspiration (DK805S*LR*) | |
| Origin Response Speed | With the same response speed as above | |
| Origin Position | Spindle movement of 1mm ±0.5mm | |
| Protection Level ※2 | Linear: IP67; Right-angle: IP64 (IP67 ※3) | |
| Vibration-resistant | 100m/s2 (20 ～ 2,000 Hz) | |
| Impact-resistant | 1000m/s2 (11ms) | |
| Power Voltage | DC 5V ±5% | |
| Power Consumption | 1W | |
| Output | A/B/Origin Differential Line Driver Signal (Compliant with EIA-422) | |
| Quality ※4 | Approx. 30g | |
| Probe | Bearing spheroidal super-hard alloy balls, installed with M2.5 screws | Steel ball surface, installed with M2.5 screws |
| Output Cable Length | 2.5m | |
| Accessories | 1 instruction manual, +2 PM4×5 screws, set screw, wrench, spring washer 1 each installation pin (only for DK8**S*F**), 1 each soft tube elbow (only for DK8**S*L**), 1 each wrench | |
