Magnetic detection method
Good environmental resistance, oil resistance, dustproof, shock and vibration resistance
Resolution: 10µm
Up to 2 meters in length
The ruler has a small size and a simple structure, making installation convenient.
From wood and stone processing machines to metalworking machinery, large-scale machinery
Main Application: Wood and Stone Processing Machines
High-Speed Response: 300m/minWith PL20CAssembled (when applicable)
| Main Specifications | ||
|---|---|---|
Precision is the value when combined with the probe cable PL20C/PL25 and the probe cable PL81/82 with the internal junction box. Changes to the recorded content will be made without prior notice. | ||
| Model | SL110 | |
| Measurement Range (L) | 200，300，400，500，600，700，800，1000，1200，1500，1600，1700，1800，2000 mm | |
| Full Length | Measurement Range: +103mm | |
| Accuracy (at 20℃)*1 | (50+10L/1000) µm Range: Measurement (mm) | |
| Permitted for parallelism installation | Grating face direction | Under 0.8mm / Full Length |
| Ruler side direction | Under 1.0mm / Full Length | |
| Coefficient of linear expansion | (10.4±1)×10-6/℃ | |
| Operating Temperature Range | -5 ～ +45°C | |
| Storage Temperature Range | -10 ～ +50°C | |
| Applicable Reader Cable | PL20C / PL25 | |
| Head cable with applicable insert box (sold separately) | PL81 / PL82 / PL25 / PL20C (for connecting monitors) | |
