Mitsubishi Calculating Digital Indicator 543-595B-10

Mitsubishi 543-595B-10 Digital Indicator with Calculating Function

543 Series

Absolute Digital Indicator ID-C112RXB2 for Calculation

● Built-in rod displacement calculation function. By setting installation calculation coefficients on various fixtures, measurement results can be directly read.

Guo is a highly scalable indicator table.

● By connecting to the computer and using the parameter setting kit (optional) and software, various settings can be made.

● Rich functionality achieved through simple operation with 5 buttons, status icons, and key-assisted display.

■ Features

● Calculation Function f(x)' ) = Ax'+ B + Cx' -1 ( x= x + offset

Peak Detection Function (High/Low)

● Amplitude Detection Function (Difference between Max and Min Values During Movement)

Note: Peak Detection Capability

Sample Rate: 10 times/second

② Capture Speed: 10 µm/second

By setting

Sample Rate: 50 times per second

② Capture Speed: 50 µm/second

Can switch

Zeroing Function (INC Measurement System Origin Setting)

● Preset Function (ABS Measurement System Origin Setting)

● Tolerance Judgment Function (ABS: Three sets, INC: Can be stored)

● Simulated gauge graduation value switch

● Feature Lock Function

● Retain Display Value Feature (No External Device Connected)

Data Output Function

External PC Setup Input Function

● Display Section Rotating Function (330°)

Low Voltage Warning Display

Error Warning Display

● Resolution Switching Function

■Selection >> See details on pages 07-11.

● Measuring Rod Lift Option

Measuring Rod Lift Rod: No. 21EZA198

Lever for Measurement Rod: No.21EZA105
