Product Description

Utilizing the thermoelectric effect of Peltier elements, when paired with a thermostatic circulation pump, cooling down to -35°C can be achieved without the need for refrigerants like liquid nitrogen.


Core Advantages

Technical Specifications

One, the system composition of the small vacuum high and low temperature probe stage includes:

Probe Stage Body

2. Microscope

3. Monitor camera components

4. Probe Mount & Fixture

5. DC Probes

6. Kelvin Probe

7. RF/Microwave Probe

8. Optical Wave Probe

9. Optical Isolation Platform

10. Adapter plug

11. Vacuum Pump

12. Additional Upgrade Components



II. Detailed Description:

(1) Overall Specifications and Features:

Weight: 30 kg

2. Dimensions: 450mm wide × 400mm deep × 600mm high

3. Enhanced ergonomic design for comfortable long-term operation by engineers.

(II) Chuck Specifications:

1. 40×40mm platform, flatness: ±3μm

2. The loading platform uses vacuum suction to hold the samples, with the small sample size being 5mm x 5mm.

3. Carriage X-Y axis fine travel 101.6mm × 101.6mm, fine resolution 1μm

4. Z-axis micro-adjustable lifting and lowering 10mm, micro-adjustable resolution 1μm

5. The carriage has a horizontal angle adjustment range of 0° to 360° with a rotation accuracy of 0.01°.

6. The loading platform is electrically independently suspended, capable of serving as a back electrode.

(3) Needle Clamp Table Specifications:

U-shaped polished stainless steel countertop

2. Pin Seat Table Flatness: ±3μm

3. Number of needle holders: 4-6.

(4) Microscope Operation Specifications:

Equipped with an adjustable arm mechanism, allowing for quick movement of the microscope in any X-Y direction.

2. The microscope's Z-axis features a focusing knob, allowing a travel distance of 50.8mm along the Z-axis with a movement precision of 1μm.

(V) Application Scenarios:

DC IV/CV Testing

2. Pulse IV Test

3. Impedance Test

4. Time Domain Analysis Test

5. Active RF Testing

6. Passive RF/Microwave Testing
