Product Introduction

2D Full-Field Displacement, 2D Full-Field Strain, 2D Full-Field Deformation Measurement.

Core Technology

Technical Specifications

The Lianhe Guangke 2D Full Field Strain Testing System is widely used in educational, scientific research, and other fields involving material mechanics, fracture impact, and vibration experiments. It primarily addresses the following measurement needs:

2D Full Field Displacement Measurement

2D Full Field Strain Measurement

2D Full-Field Deformation Measurement


Product Features

Full-field measurement, equivalent to thousands upon thousands of virtual strain gauges

Single-phase structure, effectively saving hardware costs

High-precision measurement, with the highest strain accuracy exceeding 0.002%

Universal for both large and small pieces, capable of testing specimens ranging from a few millimeters to several meters.

Traceable and repeatable for the measurement process analysis

Regional self-selection, specific analysis tailored to different regions


Product Applications

The 2D Full Field Strain Testing System is primarily used for material mechanical property testing, including:

(1) Static Testing: The 2D strain testing system allows for rapid measurement of the full-field 2D displacement, strain, and deformation on the material surface.

(2) Dynamic Testing: Experiments such as tension, compression, fatigue, and impact tests. The system can obtain relevant images, calculate displacement fields, strain fields, and deformation fields, and can also be used for research on vibration frequency, periodic amplitude, etc.

The 2D Full-Field Strain Testing System can be applied in fields such as automotive mechanics, aerospace, bridge geology, and biomechanics, helping relevant research quickly obtain data.


To achieve measurements across multiple dimensions, even a full 360-degree circular field of view (e.g., for rod-shaped specimens), we require a 3D strain testing system.
