Jingming Special Steel GH625 High-Temperature Alloy Plate, In Stock GH625 Thin Plates, Factory Pricing
Wuxi 30409 stainless steel sheet prices. S30409 stainless steel conforms to standard GB24511-2017, with the national standard grade of 07Cr19Ni10, and a carbon content of 0.04-0.1%, categorizing it as a high-carbon 304 stainless steel. Main manufacturers of 30409 stainless steel sheet: Taigang Stainless Steel, Baosteel Stainless Steel, Jiugang Hongxing Stainless Steel. Main applications of 30409 stainless steel sheet: pressure vessels, low-temperature pressure vessels, etc. Thickness of 30409 stainless steel sheet: 3.0mm-80mm. Width of 30409 stainless steel sheet: 1500mm-2500mm. Standard for 30409 stainless steel sheet: GB4511-2017. Original factory flat sheets, low price. Sizes: 14*1500*6000, 80 tons; 16*1500*6000, 80 tons; 20*1500*6000, 80 tons; 22*1500*6000, 80 tons; 25*1500*6000, 80 tons; 28*1800*6000, 5 tons; 30*1800*6000, 5 tons; 40*1800*6000, 5 tons; 50*1800*6000, 5 tons.
304H Stainless Steel Chemical Composition: Carbon C: 0.04-0.10, Silicon Si: ≤1.00, Manganese Mn: ≤2.00, Sulfur S: ≤0.030, Phosphorus P: ≤0.045, Chromium Cr: 18.00~20.00, Nickel Ni: 8.00~11.0. 304H Stainless Steel Mechanical Properties: Tensile Strength σb (MPa): ≥520, Yield Strength σ0.2 (MPa): ≥205, Elongation δ5 (%): ≥40, Reduction of Area ψ (%): ≥60, Hardness: ≤187HB ≤90HRB ≤200HV. 304H corresponds to the Chinese grade: 07Cr19Ni10.
Stainless Steel Sheets|Stainless Steel Coils Stainless Steel Tubes|Stainless Steel Bars Stainless Steel Profiles Stainless Steel Sheet Width: 1000mm, 1220mm, 1250mm, 1500mm, 1800mm, 2000mm Cold Rolled: Stainless Steel Sheet Cold Rolled 2B (Coil, Strip, Plate) Special Sheets: 3.5mm—6mm 304/2B, 316L/2B Thickness: Cold Rolled 2B (0.1—6.0mm) Surface: 2B Gloss, BA; 8K Mirror; Satin, Matte; Snowflake Sand; Scratch-Free; Decorative Panels: Color Panels, Titanium Plated, Engraved, Polished Finish (HL, NO.4), 3D Panels, Sandblasted, Embossed; Hot Rolled Department: Stainless Steel Sheet Hot Rolled (Coil, Plate) Thickness: Industrial (3-159mm) Surface: 8K Mirror; Satin, Titanium Plated, Matte; Snowflake Sand; Scratch-Free; Special Processing: Custom sizes available upon customer request Tubes: Seamless Tube, Welded Tube, Industrial Tube, Decorative Tube (Seamless, Welded, Bright, ERW), Fluid Tube, Flexible Tube, Polished Tube; Standard tube specifications exceed 200, smaller sizes are more expensive, especially capillary tubes, which are produced from 304 material to avoid cracking. Custom non-standard tube sizes are available. Seamless tubes are主要用于industrial use with a matte finish. Welded tubes have a bright finish with a fine welding line inside, commonly known as welding tube, primarily used for decorative materials. Industrial fluid tubes have pressure resistance determined by wall thickness. 310 and 310S tubes are for high-temperature applications, operating normally below 1080 degrees and withstanding temperatures up to 1150 degrees. Stainless Steel Round Bars: Bright Bar, Black Bar, Hex Bar; Large diameter round bars available for order. Stainless Steel Profiles: Angle Iron, Channel, I-Beam, H-Beam. Materials include: 1CR17MN6NI5N(201), 1CR18MN8NI5N(202), 1CR17NI7(301), 1CR18NI9(302), Y1CR18NI9(303), 0CR18NI9(304), 00CR19NI10(304L), 0CR19NI9N(304N1), 0CR19NI10NBN(304N2), 00CR18NI10N(304LN), 1CR18NI12(305), 0CR23NI13(309S), 00CR25NI20(310S), 1CR25NI20SI2(314), 0CR17NI12MO2(316), 00CR17NI14MO2(316L), 0CR18NI12MO2TI(316TI), 0CR17NI12MO2N(316N), 00CR17NI13MO2N(316LN), 0CR18NI12MO2CU2(316J1), 00CR18NI14MO2CU2(316J1L), 0CR19NI13MO3(317), 00CR19NI13MO3(317L), 1CR20NI14SI2, 1CR16NI35(330), 00CR20NI25MO4.5CU(904L), 1CR18NI9TI(321), 0CR18NI11NB(347), 1CR19NI11NB(347H), 1CR17NI12MO2(316), 00CR22NI5MO3N(2205), 00CR25NI7MO4N(2507), 1CR17(430), 1CR17MO(434), 0CR13(410S), 1CR13(410), 2CR13(420J1), 3CR13(420J2), 4CR13, 1CR17NI2(431), 9CR18(440C), 0CR17NI4CU4NB(630), 00CR18MO2(444) etc. Container Steel: S30403, S30408, S30409, S32168, S31603, S31608, S31668, S34778, S32205 Nickel Alloys: Nickel Alloys Nickel 200/201 Monel400/K500 Incoloy800 800H 800HT 825 Inconel600 601 625 686 Hastelloy C-4 C-22 C-276 etc. Just one phone call or a fax from you, and we will promptly and seriously respond to give you an understanding of the knowledge, prices, origins, tolerances, and other information about the materials you need.
Common stainless steel sheet sizes are mainly divided into cold rolled and hot rolled types. Common cold rolled sizes include 1000*2000, 1220*2440, 1220*3050, and 1500*3000. Common hot rolled sizes include 1220*2440, 1220*6000, 1500*3000, and 1500*6000. Other special specifications or non-standard sizes can be customized according to customer requirements. Standard cold rolled thickness ranges from 0.3 to 8.0mm; for thicknesses outside this range, please contact the manufacturer for discussion. Standard hot rolled thickness ranges from 3.0 to 100.0mm; for thicknesses outside this range, please contact the manufacturer for discussion.
S30408 corresponds to grade: 06Cr19Ni10, which is an Austenitic type of stainless steel. It is a versatile stainless steel commonly used for manufacturing equipment that requires excellent overall properties (corrosion resistance and formability).
Standard thicknesses of S30408 stainless steel plates: 3.0, 4.0, 5.0, 6.0, 8.0, 10.0, 12, 14, 16, 18, 20, 25, 30, 35, 40
Available Materials: {Material Provided}: 301, 304, 304L, 321, 316, 316L, 316Ti, 314, 310S, 630, 631, 904L, etc. {Specification Range}: Thickness: 0.03mm to 2mm, Width: 3mm to 610mm. {Tolerance Range}: Thickness Tolerance: ±0.05MM, Width Tolerance: Precision ±0.01MM, also available with deburring. Apart from these elements that significantly affect the properties and structure of stainless steel, stainless steel also contains other elements, some being common impurities like silicon, sulfur, and phosphorus, and others added for specific purposes such as cobalt, boron, selenium, and rare earth elements. In terms of the primary property of corrosion resistance in stainless steel, nickel, when combined with chromium, plays a crucial role. Nickel is an excellent corrosion-resistant material and a key alloying element in stainless steel. In steel, nickel is the element that forms the austenite structure. However, to achieve a pure austenitic structure in low-carbon nickel steel, the nickel content must reach 24%, and it is only when the nickel content is 27% that the steel's corrosion resistance in certain media significantly changes. Therefore, nickel cannot form stainless steel alone but must be present with chromium in stainless steel. Currently, this type of steel is mainly used in the aviation industry and rocket missile production, and its application in general mechanical manufacturing is not widespread, and it is also categorized as part of a series of ultra-high-strength steels. The corrosion resistance of stainless steel, types and definitions: One type of stainless steel may exhibit good corrosion resistance in many media, but in another, it may not. Material Composition of S30409 Stainless Steel Plate: The wall thickness has a small average dimension deviation, and the formation of thin-walled stainless steel plates is even more so due to this. But how to purchase products to ensure quality and achieve a wide profit margin is a concern. Rare full-bore welding flanges, socket welding flanges, in all tests, ultrasonic testing has become one of the most commonly used non-destructive testing methods. It is a method that detects the properties of the interface reflection by propagating ultrasonic waves through the medium.
