0Cr13Ni5Mo is a super low carbon martensitic stainless steel with excellent strength, toughness, weldability, and wear and corrosion resistance. It is produced through an improved smelting process for martensitic stainless steel, reducing carbon content and increasing nickel and molybdenum alloy elements, resulting in superior properties compared to conventional martensitic stainless steel.
0Cr13Ni5Mo Equivalent Grade:1、 GB-T Standard: Number Plate: S41595, New Number: 04Cr13Ni5Mo, Old Number: 0Cr13Ni5Mo, 2; ASTM Standard: S41500, SAE Standard: One, UNS Standard: F6NM; 3) JIS Standard: SUSF6NM; 4) DIN Standard: 1.4313; 5) EN Standard: -, X3CrNIMO13-4.
Chemical Composition: 0Cr13Ni5MoCarbon C: ≤0.05, Silicon Si: ≤0.60, Manganese Mn: 0.50~1.00, Phosphorus P: ≤0.030, Sulfur S: ≤0.030, Chromium Cr: 11.50~14.00, Nickel Ni: 3.50~5.50, Molybdenum Mo: 0.50~1.00, Nitrogen N: —, Copper Cu: —, Other Elements: —.
Physical Properties of 0Cr13Ni5Mo:Density (20℃)
/kg/dm3:7.79,Melting Point/°C: —Specific heat capacity (0~100℃)/kg/(kg·K): 0.47Thermal Conductivity / W/(m·K)
100℃-:16.3,Thermal conductivity / W/(m·K)
500℃-:-,
Coefficient of Linear Thermal Expansion
/(10-6/k)
0~100℃:10.7, Linear Thermal Expansion Coefficient / (10^-6/K)
0~591℃:-, Resistivity (20℃)
/（Ω.mm2/m):-,Longitudinal modulus of elasticity
（20℃）/GPa:201，Magnetic: Yes.
0Cr13Ni5MoMechanical properties:Delivery Status: Bar material solution treated, plate material solution washed.Tensile Strength (RM/MPa): 795Tensile Strength (Rp0.2/MPa): 620Tensile elongation A/%: 15Section reduction rate (Z/%): -
0Cr13Ni5Mo Heat Treatment: N/AHardness HBW ≤: -, Hardness HRB ≤: -Heating Temperature: N/AHeating Method: N/A.
Application Fields: Due to its excellent mechanical properties and corrosion resistance, it is widely used in the nuclear power, oil machinery, valves, and other fields.
