rla134 Standard Electric Cylinder

The electric cylinder has a short overall length, making it suitable for installations with limited space. Additionally, the imported synchronous belt used in this solution boasts high strength, minimal gaps, and a long service life, contributing to the standard electric cylinder's high controllability and precision. The servo motor pairs with the electric cylinder for flexible operation, easy installation, simple setup, and convenient use.

Product Details Introduction

One. Servo electric cylinder working principle

An electro-cylinder is a modular product with an integrated design that converts the rotational motion of a servo motor into linear motion through the mechanical movement of a screw and screw rod. By utilizing the closed-loop control characteristics of the servo motor, precise control over thrust, speed, and position can be easily achieved; combined with mechanical motion technology and programmable technology, it achieves programmable and numerical control. It is a revolutionary product that represents a new breakthrough in achieving high-precision linear motion control.

II. Electric Cylinder Types
Direct-Acting Electric Cylinder
Direct-actuated electric cylinders integrate AC servo motors, servo drives, high-precision ball screws, and modular design technologies, offering features such as compact structure, low inertia, fast response, low noise, and long lifespan. The servo motor is directly connected to the cylinder's transmission screw, reducing the inertia and clearance of intermediate links, enhancing control and precision. The servo motor is integrated with the cylinder for easy installation and convenient use. The main components of the cylinder are all made with internationally renowned brand products, ensuring stable performance, low failure rate, and high reliability.
2. Folding Electric Cylinder
Collapsible electric cylinders are suitable for installations with limited space due to their short overall length. Additionally, the imported synchronous belts used in this solution offer high strength, minimal gaps, and long service life, resulting in excellent controllability and precision for the entire cylinder. The servo motor pairs with the cylinder for flexible operation, easy installation, simple setup, and convenient use.

Section 3: Electric Cylinder Models

IV. Overview of Electric Cylinder Features

1. Precise path location and controllability
2. Modular assembly applications, saving design space for mechanical components
3. Suitable for high-speed, high-frequency operation
4. Precise and easy to install
5. Multi-point positioning and multi-segment control
6. Diverse installation options for accessories and methods available
7. Available with a variety of complete motor and controller sets.
8. A variety of products are available for selection.
9. Sleek design, low maintenance costs, and ease of operation.

V. Electric Cylinder Usage Instructions and Precautions
1. Electric cylinders are precision electromechanical integrated transmission equipment. Please carefully read the precautions and the manuals for the motor, driver, and other components before use.
2. This product features an internal high-strength magnet, equipped with a magnetic induction switch and a stroke limit warning sign externally. Please fine-tune the required stroke within the warning sign.
3. Our company uses a full-sealed unit, filled with high-quality lubricating oil, requiring no regular maintenance from the customer; for certain high-frequency and high-speed models, we have designed personalized lubricating oil injection ports.
4. When adjusting the servo electric cylinder, it should be operated at low speed with single movements first. Increase the speed only after all aspects are functioning normally to prevent damage to the electric cylinder.

Section 6: Applicability Scope
Multi-degree-of-freedom simulation and emulation, multi-degree-of-freedom motion entertainment, precision machining, robots, mechanical lifting platforms, automotive presses, automotive manufacturing equipment, mechanical automation production lines, petrochemicals, material handling, injection molding machines, mold control, valve control, precision machine tools, food industry, and more.

Section 7: After-Sales Instructions and Recommendations
1. This product comes with a 1.5-year warranty from the date of factory shipment, under normal usage conditions (excluding any man-made damage).
2. Damage caused by human factors or other abnormal use is not covered under warranty.
3. No unauthorized disassembly of the electric cylinder is allowed without the manufacturer's permission. Self-disassembly or modification are not covered under the warranty.
