Channel guard railing
Channel isolation net, South-to-North Water Transfer protection wire mesh is made by welding high-strength cold drawn wire with low-carbon steel wire, then hydraulically formed. It is secured with link attachments to steel pipe posts. It features long-lasting corrosion and UV resistance. The surface treatment of this fence mesh is galvanized and painted, or either can be chosen. The top is covered with a plastic cap or rainproof cover. Depending on the environment and installation method, options include pre-burying 50cm or adding a base. The mesh panels and posts are connected by screws and various special plastic or iron clips. The screws are anti-theft. The accessories used can also be designed according to the specific requirements of the customer.
Channel isolation net * product is a frame fence mesh, it comes in various specifications, is sturdy and durable, with surface treatment of electroplating and hot-dip galvanizing for excellent corrosion resistance, very suitable for river and canal bank protection.
Frame guardrails in channel isolation nets are highly popular compared to standard guardrails. The posts can be processed into a movable form, convenient for use in various settings. Additionally, the frame guardrails exhibit excellent shock resistance, doubling the load-bearing capacity of regular guardrails.
Product Specifications
Mesh (mm): 75x150, 80x160
Web Width (mm): 1800x3000
Fence Mesh Frame
Edge Frame (mm): 20x30x1.5 20x30x1.0
Pre-coating Wire Diameter (mm): 3-6
Welded Wire Mesh Size after Plastic Coating (mm): 4-7
Pole Dimensions (mm): 48x2x2200
Overall Bend: 30°
Bend Length (mm): 300
Pole Spacing (mm): 3000
Pile Pre-embedding (mm): 250-300
Pre-buried Foundation (mm): 500300x300 or 400x400x400
Surface Treatment: Electrostatic Powder Coating, Spray Coating, Cold Galvanizing, Hot Galvanizing, Pre-Hot Galvanizing followed by Immersion Coating
Product Advantages:
Attractive, durable, non-deforming, and quick to install, it is an ideal metal mesh wall widely adopted across various industries.
Excellent corrosion resistance at a low cost.
Usage: Isolation and protection for the South-to-North Water Diversion Project, municipal guardrails, garden beds, corporate green spaces, roads, airports, green area fences, railway enclosed nets, expressway enclosed nets, perimeter fences for industrial areas, residential community guardrails, and isolation and protection for various sports venues, industrial and mining schools.
This fence mesh features galvanized and painted surface treatment, or you can choose one option. The top is covered with a plastic cap or rainproof cover. Depending on the environment and installation method, options include pre-buried 50cm or with a base. The frame fence mesh panels and posts are connected with screws and various special plastic or iron clips. All screws are anti-theft. The accessories can also be designed according to the specific requirements of the customer.
