Introduction to Frame Fence Mesh Product Applications and Features
Frame Fence Mesh Application: Primarily used for highway (expressway guardrails), railway, civil construction, water conservancy, and various mechanical and electrical protection.
Frame Fence Mesh Features: Made of full automatic cross-welded steel wire mesh, with clean weld points and no damage, high strengthThe surface treatment method uses exterior PE or PVC coating, a mature and effective technique that can adsorb and wrap around the product surface, with strong adhesion and corrosion resistance. The PE and PVC materials are non-toxic and harmless, offering properties such as corrosion resistance, aging resistance, sun resistance, and high/low-temperature tolerance, ensuring a service life of up to 5-10 years in outdoor environments. They also exhibit long-lasting corrosion resistance and UV protection. The mesh has a high impact resistance. It boasts high strength, good rigidity, attractive appearance, and a broad field of vision. It is easy to install, feels bright, and is pleasant to use.
Product Specifications for Frame Fence Mesh
Wire Mesh: Made from coiled wire as the raw material for producing frame perimeter wire mesh, material isQ195。
Surface Treatment of Frame Fence Mesh: Galvanized, hot-dip galvanized, spray painting. Hot-dip galvanized frame fence mesh is a customerPreferred surface treatment methods.
Mesh size:1700mm high × 2500mm wide, 1800mm high × 2500mm wide, 1800×3000, 2000×3000, 1500×2500, etc.
Yarn diameterWire Diameter Range: 2.5mm - 6.0mm; Standard Sizes: 3.0mm, 3.2mm, 3.5mm, 3.8mm, 4.0mm.
Mesh size:25×75mm to 150×300mm; 50×100/75×150/50×200/60×150* are commonly used.
Border: Border: 20x30 or 20x40mm rectangular section welded pipes; 0.8/1.0/1.2/1.5mm thick square tubes.
Pillar:48mm diameter round tubes in thickness of 1.0/1.2/1.5/2.0mm. Generally, standard round tubes are available, topped with a plastic cap or rainproof cover.
Surface anti-corrosion treatment for frame fence mesh:
Frame fence mesh products are produced by welding galvanized wire or hot-dipped galvanized steel wire into shape, followed by plastic coating; or low-carbon steel.
Black silk welding directly dipped in plastic coating(PE); or first weld and shape, then apply electroplating + dipping in plastic; galvanized + spraying plastic; spraying paint, etc.
Frame Fence Mesh Installation Accessories: The mesh panels and posts of the welded frame are connected with screws and special metal clips, or bound with wire. The screws used are anti-theft automatic. The accessories for the frame fence mesh can also be specifically designed according to the different requirements of the customer.
