Technical Specifications

Fuel Gun Quantity: 1 unit

Electric Oil Transfer Pump: 220V/380VAC, 50Hz

Fuel Flow Rate: 10-18 LPM (liters per minute)

Pre-set Range: 0.01-999.9L / 0.01-999.99

Oil Injection Accuracy: ±1%

Straw Diameter: 3/4 inch, Length: 2 meters

Mail Oil Tube Specification: Diameter 1/2 inch, Length 4 meters.

Output Pressure: 5-20 Bar

Suction Oils: Various engine oils, gear oils, hydraulic fluids, and other lubricating liquids

Injection Steps: Pre-set oil quantity - workpiece in place - oil filling port secured - oil filling signal (manually provided) - metered injection - automatic stop

Features

■ Hardware selection is reliable, stable, cost-effective, easy to operate, and user-friendly interface.

■ The quantitative oiling detection uses a flowmeter with good repeatability.

The equipment boasts an aesthetically pleasing design and is user-friendly.

Select products with high pressure resistance, short operation time, long lifespan, and high reliability for valves.

■ The average failure-free time of the control system is greater than 50,000 hours.

Digital preset, modification, storage, and annotation of numerical values

■ Precision marking can be calibrated to ensure accuracy of dispensing

■Real-time display of working status

■ Single filling amount, cumulative filling amount, etc., parameter numbers displayed

Automatic batch marking of production line parts



Application

■ Volumetric Filling System: Customizable combinations to meet various requirements, catering to user needs. The system is stable, reliable, efficient, and maintains a clean working environment.

■ Application Industry: Lubricant filling for engine, transmission assembly lines, construction machinery, home appliances, electricity, petrochemicals, etc.

■ Application Media: Engine Oil, Double Helix Gear Oil for Transmission, ATF Oil, Windshield Washer Fluid, Antifreeze, Power Steering Fluid, Windshield Cleaning Fluid, etc.

Modular structure, available for selection and configuration as needed. Based on the actual on-site conditions and production requirements, our company can customize various fluid quantitative dispensing oil systems. Suitable for on-site quantitative oil dispensing; also applicable for long-distance transportation and refueling at oil depots.



Operation Instructions

Plug in the power

2. Pre-set dosing quantity

2. Hold the marking gun aimed at the fueling port

3. Pull the trigger to start fueling. The electric fuel pump will automatically start/stop based on the opening/closing of the fueling gun.
