Brand: NanGong, Model: NGTT18-10/25-8S, Table Size: 10*2.5 meters, Load Capacity: 18 tons, Color: Matte Black, Net Weight: 5.7 tons.
18-ton dual-axle flatbed trailer detailed specifications:
This vehicle has a carrying capacity of 18 tons, with the main structure made of steel焊接. The platform measures 10 meters in length and 2.5 meters in width, covered with 5MM patterned steel plates. The reinforced beam under the chassis is elevated 600mm or more from the ground.
2. This vehicle comes with 8 models of solid fitment tires, 18*9*12-1/8, each wheel carries a load of 3.2T and has a rated speed of 15KM/H.
3. This vehicle is designed with a suspension concept, capable of automatically adjusting the body level and tire load balance according to the road flatness.
4. Front wheels have a steering angle of 180 degrees on each side, facilitating tight-radius turns.
5. The steering mechanism is a turntable-style machinery turntable assembly (18T), offering smooth operation and a long service life.
6. This vehicle features bidirectional towing with spring suspension.
7. Provide a connector and plug.
8. The platform requires tapped screw holes (for shelf installation), and the connection area needs reinforcement (the pitch and diameter of the tapped holes must be provided).
9. Color: Matte black with yellow caution stripes around the edges.
10. Equipped with hydraulic braking system (handbrake).
18-ton dual-axle flatbed trailer, Nanong brand, long-term non-standard customization
Application: The 18-ton double-axle flatbed trailer is commonly used in industries such as ceramics, hardware, and chemicals. Generally, solid tires or pressure-fit tires with strong load-bearing capacity and smaller tire diameters are used.
