The Role of Relay Protection

Relay protection is a crucial measure for detecting faults or anomalies in the power system, thereby triggering alarm signals or directly isolating and removing the faulty parts. Its primary functions include: 12

Quickly Disconnect from Fault: In the event of a fault in the power grid that is sufficient to damage equipment or threaten the safety of the power grid, quickly disconnect the protected equipment to prevent the fault from escalating.

Proactive Alert Signals: Timely issuance of alert signals for abnormal operations of the power grid and certain equipment's irregular status, enabling prompt handling and restoration to normalcy.

Achieving automation and remote control in power systems: as well as automatic control in industrial production, such as automatic closing of switches; automatic engagement of backup power sources; remote control, remote measurement, and remote signaling, etc.

The application of relay protection devices is very extensive, including but not limited to high-voltage power supply systems in factories and enterprises, substation facilities, and is used for line protection in high-voltage power supply systems, main transformer protection, capacitor protection, and more. With the rapid development of relay protection technology, microcomputer protection devices are increasingly being put into use, enhancing the reliability of protection.

The fundamental concept and function of relay protection are based on the physical quantities that constitute relay protection actions, which are changes in electrical quantities (current, voltage, power, frequency, etc.) in the power system during component short-circuits or abnormalities. Its basic task is to, upon the occurrence of faults or abnormalities in the power system, automatically disconnect the faulty equipment from the system within a short time and small area, or send signals for the on-duty personnel to eliminate the root cause of the abnormal conditions, in order to avoid or mitigate equipment damage and reduce the impact on power supply to neighboring areas.
