The Intelligent DC Low Resistance Tester (1μΩ~20kΩ) is specifically designed for testing various resistances. The ED2512B can measure resistances ranging from 1μΩ to 20kΩ.

The unit is equipped with an additional sorting function. During the sorting state, you can choose to display resistance values or percentage values. It can also judge if the resistance value is too high, too low, or a good product based on the set values.

The machine boasts the following features:

Wide resistance testing range: 7 test steps from 20mΩ to 20kΩ (1μΩ to 20kΩ).

B. Variable Test Speed: Slow - 2.5 times/second, Fast - 10 times/second.

C. High Precision: Basic accuracy: 0.2% + 2 digits.

D. Two display modes: Resistance value or percentage value.

Sorting Function: LOW, PASS, HIGH, Buzzer Output.

Function: Panel Keypad Reset Feature

This instrument adheres to the product standard: JB/T7585-94.
