Product Introduction
The 13X molecular sieve has a pore size of 10Å, capable of adsorbing molecules smaller than 10Å, and is used for the deep drying of general gases, removing H2O and CO2 in air separation units. The 13X can adsorb the same molecules that 3A, 4A, and 5A can, and it can also adsorb molecules with a larger critical diameter, such as aromatic and straight-chain hydrocarbons.
Specific Applications:
Air purification in the air separation unit, removing water, carbon dioxide, and hydrocarbons.
For general gas deep drying.
Drying and desulfurization of liquid hydrocarbons.
Catalyst Support
Parameter
Project | Unit | Technical Indicators | |||
Shape | Bar Code | Spherical | |||
Specs | mm | 1/16″ | 1/8″ | 1.7-2.5 | 3.0-5.0 |
Granularity | % | ≥98 | ≥98 | ≥98 | ≥98 |
Stacking Density | Kg/m³ | ≥620 | ≥620 | ≥640 | ≥640 |
Wear rate | % | ≤0.20 | ≤0.20 | ≤0.20 | ≤0.20 |
Compressive Strength | N | ≥30 | ≥45 | ≥30 | ≥70 |
Static water adsorption capacity | wt% | ≥26 | ≥26 | ≥26 | ≥26 |
CO2 Adsorption Capacity | wt% | ≥18 | ≥18 | ≥18 | ≥18 |
Water Content in Packaging | % | ≤1.5 | ≤1.5 | ≤1.5 | ≤1.5 |
Packaging
25KG paper box, lined with PP sealed bags
235L sealed steel drum (Net weight: 150 kg)
Liner-sealed polypropylene container bags(600 lbs. or 750 lbs.)
Storage
Store in a well-ventilated, dry storage facility. Be mindful of moisture prevention and protect from rain during transportation.。Avoid adsorption of water and organic matter prior to use; regenerate if necessary.
