The waste transfer semi-trailer is a waste transport vehicle developed by our company to meet the requirements of long-distance and high-load transportation. It is primarily used in large-scale waste transfer stations and power plants.
The vehicle can be directly connected to waste compaction trucks and compaction stations, as well as various waste transportation equipment. It features a chassis with a containerized body, pusher blade, rear door, and hydraulic system.
Assembled from electrical systems and other components.
This product is mainly composed of the frame, body, pusher, feed door, rear door, hydraulic system, electrical system, etc., and is primarily used for loading, transporting, and unloading domestic waste.
He's trash. The frame is mainly composed of the underframe, drawbar, axle, suspension, ABS, leaf springs, legs, and other components; the underframe beam is in the shape of an I-beam, and the goose neck section
Double flanged, with the beams bent into C-shape, all made of high-strength plates, wheelbase of the axle 1840mm, equipped with ABS on the first and third axles, and featuring the best design configuration such as American leaf spring suspension; all components are selected
Utilize renowned brands both domestically and internationally.
The cabinet structure is mainly composed of the van body, push blade, rear door, feed door, waste water tank, and locking mechanism, etc.
★Body: Constructed with 4mm high-strength steel plate, offering high strength, wear and corrosion resistance; the overall side features an arched design and external reinforced rib layout; the rounded body design, with...
Narrower design for even loading, low center of gravity, and strong stability; the body has an effective cargo volume of up to 47 m³; compression ratio 1:0.65, capable of transporting 26~30 tons of domestic waste per trip.
Extra-large capacity delivers exceptional cost-effectiveness.
★Push Broom: Made of high-strength steel plates and profiles, equipped with a waste scraper on all sides; preventing waste from entering the rear area of the push broom during loading and unloading.
★Back door: Constructed with high-strength aluminum alloy frames and high-strength steel plates, the arched design ensures more even distribution of force during loading, with no residue left upon unloading.
★Feed Door: A large-sized feed door is set at the top of the body, catering to the feeding needs of most equipment; high-performance rollers are installed on both sides of the feed door for smooth and frequent operation.
★Wastewater Tank: Equipped with a large-capacity wastewater tank for collecting wastewater from garbage loading or leachate, facilitating centralized discharge.
★Locking Mechanism: The rear door locking mechanism features a dual locking design, with one for the opening and closing of the rear door, and the other for a secondary lock after the rear door is closed; accompanied by installation
High-performance backdoor access
★The sealing strip ensures that there is no leakage of wastewater during loading and transportation, as it is installed together with the rear door.
★Control section: Composed mainly of components such as the hydraulic oil tank, motor, radiator, valve group, control box, and operation box. All main components are sourced from renowned brands both domestically and internationally.
This product is controlled by a control box with buttons and levers, featuring 1 control box. The control box is located at the rear end of the driver's side body.
Operation Switch and Indicator Light Instructions:
Emergency Stop Button: Press this button in the event of an abnormality or emergency danger.
2. Power Switch: Controls the power on and off of the system.
3. Power indicator light: This light illuminates when the power switch is turned on and the power is supplied.
4. Alarm Indicator: This light illuminates when the equipment encounters a malfunction.
5. Push-out/Pull-in Action Knob: After the motor is activated, clockwise rotation operates the system to push the bucket out, while counter-clockwise rotation executes the pull-in action.
6. Lid Open/Close Knob: After the motor is activated, turning the knob to the left operates the lid open function, and turning it to the right operates the lid close function.
7. Start/Compress Button: Press this button to start the motor when it is not running; after the motor starts, press the button again to initiate the cyclic compression action.
8. Rear door open/close control: After the motor is activated, the lock hook is fully released, clockwise rotation initiates the rear door open action, and counterclockwise rotation executes the rear door close action.
9. Lock hook/Release action knob: After the motor is activated and the rear door is fully closed, turning the knob to the left initiates the lock hook action, while turning it to the right executes the release hook action.
